1. Bed Frame:

   Welded with thickened 30×60×1.2mm rectangular steel tubes using advanced welding technology, ensuring high welding quality, firm structure and high stability. Load capacity: ≥250kg.
2. Bed Deck:

   Stamped in one piece from cold-rolled steel plate ≥1.0mm thick. The bed surface adopts a concave design with good ventilation, providing high comfort for patients and preventing the mattress from shifting left and right. The bed board is integrally stamped with a multi-hole design, and the back bed board adopts a dual-support structure.
3. Hand Crank System:

   The lifting screw is made of 45# steel with a smooth and durable surface. The crank handle adopts a universal joint structure, which is safe, reliable, labor-saving and noiseless. The crank knob is injection-molded in one piece with ABS engineering plastic, equipped with anti-collision design and three-speed folding function.
4. Surface Treatment:

   After sandblasting and rust prevention, the whole bed is coated with high-grade antibacterial powder by electrostatic spraying, which is environmentally friendly and antibacterial.
5. Headboard & Footboard:

   Made of ABS engineering material by one-piece blow molding, stable for long-term leaning without deformation. Built-in locking switches allow secure locking and easy disassembly. Streamlined design, elegant appearance and no sanitary dead corners. A patient information card slot is provided on the outer side of the footboard. Both sides of the headboard and footboard are equipped with built-in locking devices for quick disassembly and CPR function. The locking mechanism is made of metal components.
6. ABS Four-Section Guardrails:

   Height adjustable up and down. Equipped with a pneumatic deceleration device during lowering to prevent rapid falling, ensuring higher safety.
7. Mattress:

   Filled with 4cm high-quality coconut palm fiber + 2cm high-density sponge, soft, comfortable and durable. Covered with high-grade waterproof canvas, available in green or blue. Zippers on both ends allow easy removal and washing.
8. Dining Table:

   ABS one-piece stretchable dining table, width adjustable freely. It can be hung on the guardrail when in use and on the headboard when not in use. Position is adjustable as required. ABS hooks on the back make operation simple and convenient.
9. IV Stand:

   The whole bed is equipped with 2 IV stand sockets; IV stand is optional.
10. Casters:

    125mm diameter high-performance medical double-wheel casters. Double-wheel design avoids hair entanglement; easy to push, wear-resistant and silent. Operated with central control braking system and foot brake pedal, specially designed for medical use.

Standard Configuration
